Automatic 2 in 1 Straightener Sheet Metal Decoiler 15m/min 0.5-3.2mm Thickness

Automatic 2 in 1 Straightener

Sheet Metal Decoiler 15m/min

3.2mm Thickness Sheet Metal Decoiler

Place of Origin:

China

Brand Name:

QIAOSEN

Certification:

CE / ISO14001

Chat Now

Request A Quote

Product Details

Place Of Origin:

Guangdong, China

Type:

Feeder Machine

Use:

Sheet

Video Outgoing-inspection:

Provided

Machinery Test Report:

Provided

Core Components:

Bearing, Motor

Brand Name:

Qiaosen

Voltage:

380

Power(w):

Warranty:

1 Year

Key Selling Points:

Easy To Operate

Weight (kg):

1200

Feeding Speed:

15 M/min

Item Name:

Pneumatic & Mechanical Feeding Straightening Feeder

Keyword:

Straightening Feeder

Thickness Of Material:

0.5-3.2mm

Max Material Weight:

1200kg

Coil Intside Diameter:

450-530mm

Coil Outside Diameter:

1200mm

Function:

Metal Straightening Machine

Machine Weight:

320kg

Package:

Standard Package(wooden Box)

Payment:

T/T, Paypal, West-union, Trade Assurance

Highlight:

Automatic 2 in 1 Straightener

Sheet Metal Decoiler 15m/min

3.2mm Thickness Sheet Metal Decoiler

Payment & Shipping Terms

Minimum Order Quantity

Price

$2,860/cases 1-4 cases

Payment Terms

T/T

Supply Ability

1set 7days

Electric Decoiler Uncoiler Machine with Mechanical Expansion Structure

Chat Now

GO-500 Metal Straightening Machine 15m/min 500mm Width 3.2mm Max Thickness

Chat Now

MT-200 Metal Straightening Machine 200mm Max width 1.6mm Steel Plate Thickness for Metalworking

Chat Now

GO-400 Metal Straightening Machine Adjustable 380V For Various Metal Products

Chat Now

+8618103082715

titi@qiaosenmachinery.com

86-0769-26626853

Chat Now

Product Description

Qiaosen Automatic 2-in-1 Metal Straightening Construction Machinery Steel Plate Coil Decoiler Press Feeder Roll

Roll forming machine decoiler sheet metal straightening machine roller feeder decoiler machine

Product Specifications

Item name	GO200	GO300	GO400	GO500	GO600	GO700
Material width(mm)	200	300	400	500	600	700
Leveling thickness(mm)	0.5-3.2	0.5-3.2	0.5-3.2	0.5-3.2	0.5-3.2	0.5-3.2
Material diameter	450-530	450-530	450-530	450-530	450-530	450-530
Material outer diameter(mm)	1200	1200	1200	1200	1200	1200
Material weight(kg)	800	1000	1200	2000	2500	2500
Correction speed	15m/mim	15m/mim	15m/mim	15m/mim	15m/mim	15m/mim
Motor HP	1HP	2HP	2HP	3HP	3HP	3HP
Expansion method	Manual	Manual	Manual	Manual	Manual	Manual
Machine weight(kg)	1000	1100	1200	1400	1600	1800
Overall dimension(mm)	200014001400	210015001500	220016001600	230017001700	240018001800	250019001900

Key Features

Suitable for the collection and delivery of various coil materials, both thin metal and non-metal materials
Motor power can be added to match the feeding device
The tension of the brake device can be adjusted, and the main shaft uses a reinforced type to make the material reel rotate more smoothly and increase the load force
Indispensable parts for fully automatic production of presses, saving manpower, material resources, reducing costs, and achieving ideal results
Imported parts are used, with fewer failures and long life

Product Images

Similar Products

Company Profile

Dongguan Qiaosen Machinery Co., Ltd which have our own factory located in Jiangsu province, established in 2016, Closed to shanghai city and transportation is very convenient, a birth place of creative minds and gifted talents. Our factory took the lead in passed authentication of the ISO9001:2008 quality management system. A factory specialized in the production of hydraulic press machine. Mainly products 10 tons to 2000 tons press machine with 8 series, have more than 100 types, link single column, four column, c frame, h frame and all kinds of press machine, punching machine, folding machine, cutting machine, is used in aviation, space flight, automobile, ship, light appliance, daily used hardware and so on. All along, the company products with exquisite design, reasonable price, excellent quality and efficient after-sales service and technical support, received the affirmation of customers at home and abroad, sell well in more than 20 domestic provinces, cities and districts, and exported to United States, Japan, Russia, European Union, southeast Asia, the Middle East and other countries.

Frequently Asked Questions

Q: Are you manufacturer?

A: Yes, we are manufacturer for more than ten years.

Q: What kind of payment term you can do?

A: We are flexible about payment terms, please contact us for details.

Q: What info you need before you make the proposal for a roll forming machine?

A: The profile drawings, material informations, your special requirements.

Q: What I should do if I just start to know roll forming machinery?

A: Contact us immediately, we provide free consultant pre-sales service.
