Electric Decoiler Uncoiler Machine
JM series electric driven light-duty decoiler material rack designed for automatic support and steady unwinding of medium & small size metal coils in stamping production lines.
Applicable Materials
Suitable for carbon steel, stainless steel, galvanized steel, aluminum coil, iron strip and other common thin & medium metal coils.
Material & Craft
- Solid thickened steel frame, firm structure and good anti-deformation performance
- Main mandrel with precision machining and hard chrome plating, wear-resistant and durable
- Stable mechanical expansion clamping structure, reliable coil fixing
- Integrated motor drive system, smooth running and low failure rate
- Whole machine with anti-rust paint surface treatment, long service life
Core Advantages
- Electric automatic driving, stable continuous uncoiling
- Mechanical expansion design, simple coil loading & unloading
- Compact body, small space occupation for workshop
- Easy operation and low daily maintenance cost
- Perfectly matched with straightener & feeder for automatic stamping line
Product Specifications
| Item |
SML-100 |
SML-200 |
SML-300 |
SML-400 |
| Width of material |
100mm |
200mm |
300mm |
400mm |
| Thickness of material |
0.3-1.2mm |
0.3-1.2mm |
0.3-1.2mm |
0.3-1.2mm |
| Roller arrangement |
up 7/down 8 |
| Adjustment method |
four point independent |
| Leveling speed |
0-16m/min |
Key Features
This series of precision leveling machines is specially designed for correcting thin materials such as stainless steel, copper, and aluminum, achieving a perfect leveling effect.
The leveling rollers are made of solid steel, undergo high-frequency treatment, quenching to HRC60°, grinding, and then hard chrome plating.
The leveling points are adjustable with screws and come with two dial indicators.
Equipped with leveling auxiliary rollers to prevent bending and deformation, strengthening leveling strength and roller lifespan while meeting surface flatness requirements.
Product Packaging
Company Profile
Dongguan Qiaosen Machinery Co., Ltd, established in 2016, operates its own factory in Jiangsu province near Shanghai with convenient transportation access. The company holds ISO9001:2008 quality management system certification and specializes in hydraulic press machine production.
Product range includes 10-ton to 2000-ton press machines across 8 series with over 100 types, including single column, four column, C-frame, H-frame presses, punching machines, folding machines, and cutting machines. Applications span aviation, aerospace, automotive, shipbuilding, light appliances, and daily hardware.
Products are recognized for excellent design, competitive pricing, superior quality, and efficient after-sales service, serving domestic markets across 20+ provinces and international markets including United States, Japan, Russia, European Union, Southeast Asia, and Middle East.
Frequently Asked Questions
Are you the manufacturer? Can we visit your factory?
We are the manufacturer located in Wuxi city. We welcome you to visit our factory and check our machine quality on site. Any questions will be solved immediately.
What are your main products and main foreign markets?
Our main products include punching machines, metal straightening machines, and servo feeders. Our main foreign markets are Asia, North America, Europe, and Africa.
What are the advantages of your machines and how can I trust the quality?
Our machines feature imported quality components and are backed by a professional quality inspection team. Each machine undergoes rigorous testing before shipment, ensuring stable and reliable performance.
Will you update production process information after placing an order?
After order confirmation, we provide regular updates on production details via email and photos.
Can we be your agent?
Yes, we are seeking global agents. We provide comprehensive support including technical assistance and after-sales service, along with competitive discounts and commissions.
What are your payment terms?
We accept T/T, L/C, Western Union, PayPal, and other secure payment methods.
How long is your warranty?
We offer 12 months free warranty with lifelong maintenance support.
Do you accept customer logos and customization?
Yes, we accept various customizations including logos and machine modifications according to customer requirements.
