Single Crank Pneumatic Stamping Press 60Ton Heavy Duty Metal Forming Machine
Product Introduction
The Qiaosen ST-60 is a 60-ton general-purpose precision power press, highly popular for small and medium metal stamping applications. It is widely used in electronic parts, home appliance components, and new energy hardware production.
Featuring an open C-frame design, the machine enables easy mold installation, adjustment, and workpiece handling, even for inexperienced operators. The heavy-duty welded frame undergoes stress relief treatment, ensuring stable performance without deformation during extended mass production.
Equipped with six-sided slide guidance, the slider moves with precision, ensuring consistent part dimensions, minimal burrs, and low defect rates. The integrated overload protection system automatically halts operation when material is too thick or molds become stuck, safeguarding both machine and tooling from damage.
Operating with smooth, low-noise, and low-vibration performance, the machine supports jog mode, single stroke mode, and continuous production mode, making it suitable for both small batch and high-volume orders.
Capable of processing cold rolled steel, galvanized steel, stainless steel, aluminum, and other thin metal sheets, it performs punching, bending, forming, shallow drawing, and trimming operations.
The press can be integrated with decoilers, straighteners, and servo feeders to create fully automated stamping lines, significantly reducing labor costs and enhancing production efficiency.
Core Advantages
- Stable and rigid frame construction prevents deformation during continuous stamping, ensuring long service life
- Precise six-sided guide design guarantees accurate stamping, uniform sizing, and smooth workpiece surfaces
- Reliable overload protection prevents mold damage and machine breakdowns, reducing maintenance costs
- Simple operation and rapid mold change capabilities provide flexibility for diverse product requirements
- Low vibration and noise operation suitable for extended factory production cycles
- Excellent compatibility with automatic feeding systems for unmanned production implementation
Application Scope
Applicable Materials: Cold rolled steel, galvanized steel, stainless steel, aluminum sheet, copper sheet
Processing Methods: Punching, blanking, bending, forming, shallow drawing, trimming, progressive die stamping
Final Products: Electronic terminals, hardware shrapnels, clips, gaskets, home appliance parts, new energy components, automotive small hardware parts
Optional Accessories
Safety light curtain, automatic lubrication system, variable frequency speed control, die cushion
Automatic Production Line Matching
Decoiler / 2 in 1 Straightener Decoiler → Servo Feeder → Oil Feeder → ST-60 Power Press
Technical Specifications
| No |
Item |
Unit |
ST-60V |
| 1 |
Punching capability |
ton |
60 |
| 2 |
Impact force location |
mm |
4 |
| 3 |
Slider strokes per minute |
SPM |
35-90 |
| 4 |
Slider length |
mm |
120 |
| 5 |
Max die shut height |
mm |
310 |
| 6 |
Slider adjustment amount |
mm |
75 |
| 7 |
Up platform area |
mm |
700×400×70 |
| 8 |
Down platform area |
mm |
900×500×80 |
| 9 |
Shank hole |
mm |
Ø50 |
| 10 |
Main motor power |
kw×p |
5.5×4 |
| 11 |
Air pressure |
kg/cm² |
6 |
| 12 |
Punch accuracy grade |
|
JIS 1 |
| 13 |
Slider adjustment device |
|
Manual operation |
| 14 |
Slider center to machine distance |
mm |
225 |
| 15 |
Platform to floor distance |
mm |
785 |
| 16 |
Punch weight |
ton |
5.6 |
| 17 |
Punch dimension (L×W×H) |
mm |
1595×1000×2800 |
| 18 |
Die cushion capacity |
ton |
3.6 |
| 19 |
Stroke |
mm |
70 |
| 20 |
Active area |
mm² |
350×300 |
Product Configuration
Factory Strength & Service
Qiaosen Machinery specializes in stamping equipment manufacturing. Every machine undergoes comprehensive testing before delivery to ensure consistent quality. We provide individual machine equipment and complete automated stamping line solutions with professional after-sales support.
Warranty and Service
- One-year comprehensive warranty for the complete press machine
- All spare parts readily available with most components manufactured in-house
- Easy access to electrical parts utilizing internationally recognized brands
- Technical training and consulting available via email, phone, or video conference
- Engineer dispatch available for service, installation, or training at reasonable additional cost
- Comprehensive English operation and maintenance manual provided with each press
- Certificate of conformity included with every machine
Frequently Asked Questions
Q1: What kind of metal materials can the Qiaosen ST-60 press process?
A1: This 60-ton stamping press accommodates most common thin and medium metal sheets, including cold rolled steel, galvanized steel, stainless steel, aluminum, and copper sheets. It is ideally suited for routine hardware stamping production requirements.
Q2: What stamping processes and products is this machine suitable for?
A2: It supports punching, blanking, bending, shallow drawing, trimming, and progressive die stamping operations. Widely utilized for producing electronic terminals, spring clips, gaskets, home appliance accessories, new energy components, and automotive micro hardware parts.
Q3: Does the ST-60 power press have stable stamping precision?
A3: Absolutely stable. The machine conforms to JIS Class 1 international precision standards and incorporates six-sided slide guide structure. It operates with minimal clearance and no offset, ensuring consistent workpiece dimensions and low defect rates for long-term mass production.
Q4: Can this machine connect with automatic production equipment?
A4: Yes. It features complete automation interfaces and can be seamlessly integrated with decoilers, 2-in-1 straightener decoilers, servo feeders, and oil feeders to establish fully unmanned automated stamping lines, significantly reducing labor costs.
Q5: Is the machine safe during long-time continuous operation?
A5: Exceptionally safe. Equipped with a built-in hydraulic overload protection system, it automatically releases pressure and stops operation during overload conditions or mold jams, effectively protecting both machine structure and tooling from damage.
Q6: Is it easy to operate and adjust molds for new operators?
A6: The operational system is straightforward and user-friendly. It supports jog adjustment, single stroke testing, and continuous production modes. Mold replacement and parameter adjustments are rapid, making it suitable for multi-product flexible manufacturing.
Q7: How about the machine's operating noise and stability?
A7: Utilizing precision crankshaft and gear transmission mechanisms, the machine operates with minimal vibration and noise. The integral stress-relieved frame effectively prevents deformation, supporting 24-hour continuous factory production.
Q8: What optional accessories can be upgraded for the ST-60 press?
A8: Based on production requirements, it can be enhanced with safety light curtains, automatic centralized lubrication systems, variable frequency speed regulators, and die cushions to improve production safety and machining effectiveness.
Q: What products can this machine process?
A: It is extensively used for various thin sheet small hardware, electronic components, home appliance parts, and new energy components.
Q: Can this machine work with automatic production lines?
A: Yes, it can integrate with decoilers, straighteners, and feeders to achieve fully automated unmanned stamping operations.
Q: Is the machine precision stable?
A: It achieves JIS Class 1 precision standards with six-sided slide guidance, ensuring long-term stable stamping accuracy and consistent product quality.
