Name: High Accuracy 200ton Pneumatic Power Press Machine for Metal Stamping
Brand: Dongguan Qiaosen Machinery Co., Ltd.
SKU: ST-200
Price: 1.00 USD
Availability: InStock

Home > Products > C Frame Punch Press >

High Accuracy 200ton Pneumatic Power Press Machine for Metal Stamping

200ton Pneumatic Power Press Machine

Metal Pneumatic Power Press Machine

High Accuracy Metal Stamping Machine

Place of Origin:

China

Brand Name:

QIAOSEN

Certification:

CE / ISO14001

Model Number:

ST-200

Chat Now

Request A Quote

Product Details

Weight:

3.8 Tons

Dimensions (L×W×H):

1575×950×2500 Mm

Motor Power:

5.5 KW

Voltage:

380V

Model Number:

ST-200V

Punching Capacity:

200 Ton

Highlight:

200ton Pneumatic Power Press Machine

Metal Pneumatic Power Press Machine

High Accuracy Metal Stamping Machine

Payment & Shipping Terms

Minimum Order Quantity

Price

Price $4,685/cases 1-2 cases

Packaging Details

WOODEN BOX

Delivery Time

25-60

Payment Terms

T/T

Supply Ability

100SET per month

25ton Metal Sheet Punching Machine 60-140 SPM Slider Strokes 2.1T Punch Weight

Chat Now

ST-35V 35t Thin Sheet Metal Stamping Press for Electronic / Automotive Industries

Chat Now

60ton C Frame Punch Press High Precision for Metal Processing

Chat Now

ST-60V 60 Ton Pneumatic Punching Machine JIS 1 Grade With High Strength Alloy Crankshaft

Chat Now

86-0769-26628519

titi@qiaosenmachinery.com

86-0769-26626853

Chat Now

Product Description

High Precision Pneumatic Punching Machine

Professional 200-ton pneumatic punching machine designed for tin can lid production and high-quality metal bearing manufacturing used in motor pumps and engines.

Product Specifications

Machine Type	Punching Machine
Power Source	Pneumatic
Voltage	380V
Motor Power	5.5 kW
Model Number	ST-200V
Weight	3.8 tons
Dimensions (L×W×H)	1575×950×2500 mm
Place of Origin	Guangdong, China
Brand Name	QIAOSEN

Technical Performance Data

Parameter	Unit	V Type	H Type
Punching Capacity	ton	200
Impact Force Location	mm	6	3
Slider Strokes per Minute	SPM	20-50	50-70
Slider Length	mm	200	100
Max Die Shut Height	mm	460	510
Slider Adjustment Amount	mm	110
Up Platform Area	mm	1130×630×90
Down Platform Area	mm	1400×820×160
Main Motor Power	kW×p	18.5×4
Air Pressure	kg/cm²	6
Punch Weight	ton	23

Performance Features

High-strength fuselage structure with minimal deformation and high precision
OMPI pneumatic dry clutch brake system
Slider with 2-corner and 6-sided guides for enhanced stability
Slider guide featuring high-frequency quenching and rail grinding process for reduced wear and extended service life
Crankshaft made of high-strength alloy 42CrMo (1.3 times stronger than 45 steel)
Copper sleeve made of tin phosphor bronze ZQSn10-1 (1.5 times stronger than ordinary BC6 brass)
Highly sensitive hydraulic overload protection device for press and die longevity
Optional air cushion available

Product Configuration

Warranty & Service

One year warranty for complete press machine
Comprehensive spare parts availability
International brand electrical components
Technical training and consulting via email, phone, or video
On-site engineer service available
English operation and maintenance manual included
Certificate of conformity provided

Quality Assurance

Machinery test report and video outgoing-inspection provided
