Name: STC-200V High Accuracy Pneumatic Power Press Machine 200t with Progressive Templates
Brand: Dongguan Qiaosen Machinery Co., Ltd.
SKU: STC-200
Price: 5.00 USD
Availability: InStock

Home > Products > Double Crank Power Press >

STC-200V High Accuracy Pneumatic Power Press Machine 200t with Progressive Templates

200t Pneumatic Power Press Machine

High Accuracy Punching Press Machine

Progressive Templates Pneumatic Power Press

Place of Origin:

China

Brand Name:

QIAOSEN

Certification:

CE / ISO14001

Model Number:

STC-200

Chat Now

Request A Quote

Product Details

Power Source:

Pneumatic

Voltage:

380V

Motor Power:

15 KW

Model Number:

STC-200V

Weight:

30.5 Tons

Dimensions (L*W*H):

2235*2620*3849 Mm

Highlight:

200t Pneumatic Power Press Machine

High Accuracy Punching Press Machine

Progressive Templates Pneumatic Power Press

Payment & Shipping Terms

Minimum Order Quantity

Price

$65,716/cases 1-9 cases

Packaging Details

WOODEN BOX

Delivery Time

25-60

Payment Terms

T/T

Supply Ability

100SET per month

STC-200V High Accuracy Pneumatic Power Press Machine 200t with Progressive Templates

Chat Now

video

Durable Double Crank Power Press Designed for Heavy Duty Metal Stamping and Fabrication Tasks in Industrial Production Lines

Chat Now

Automatic Pneumatic Punching Machine 250t for Precision Metal Stamping

Chat Now

STC Steel Frame V Press Punching Machine 250ton JIS Class 1 for Heavy Metal Stamping

Chat Now

86-0769-26628519

titi@qiaosenmachinery.com

86-0769-26626853

Chat Now

Product Description

STC-200V Fully Automatic Wall Punching Machine

High-precision automatic punching machine for switch & outlet production with progressive templates and motor pump core manufacturing capabilities.

Product Specifications

Model: STC-200V

Punching Capacity: 200 ton

Power Source: Pneumatic

Motor Power: 15 kW

Voltage: 380V

Slider Stroke: 25-45 SPM

Technical Specifications

Specification	Value	Unit
Punching Capability	200	ton
Slider Strokes Per Minute	25-45	SPM
Slider Stroke Length	250	mm
Slider Adjustment Amount	120	mm
Up Platform Area	1850×650×95	mm
Down Platform Area	2400×840×170	mm
Platform to Floor Distance	1070	mm
Main Motor Power	18.5×4	kW
Air Pressure	6	kg/cm²
Machine Dimensions	2235×2620×3849	mm
Machine Weight	30.5	ton

Performance Features

High-strength fuselage structure with minimal deformation and high precision
OMPI pneumatic dry clutch brake system
Slider with two corner and six-sided guides using high-frequency quenching and rail grinding process
Crankshaft made of high-strength alloy 42CrMo for extended service life
Copper sleeve made of tin phosphor bronze ZQSn10-1 for superior strength
Highly sensitive hydraulic overload protection device
Standard SMC pressure regulator, oil mister, and air filter
Optional mat (air cushion) available

Key Advantages

Japanese JIS 1 class standard design and inspection
High precision and stability with 0-0.02mm deviation on crankshaft
Energy efficient operation with OPMI pneumatic dry clutch brakes
Improves material utilization to 105%-108%
Saves 25%-35% energy consumption (approximately 4004 kWh per year)
Famous brand electrical and pneumatic components for reliability
Photoelectric protection and multiple safety devices

Product Configuration

Warranty & Service

One year warranty for complete press machine
Comprehensive spare parts availability
International brand electrical components
Technical training and consulting via email, phone, or video
On-site engineer service available
English operation and maintenance manual included
Certificate of conformity provided

Quality Assurance

Machinery test report and video outgoing-inspection provided to ensure product quality and performance.

Manufacturer Information

Dongguan Qiaosen Machinery Co., Ltd. operates its own factory in Jiangsu province, established in 2016. Strategically located near Shanghai with excellent transportation access, our facility specializes in pneumatic press machinery production. We maintain ISO9001:2008 quality management system certification and offer comprehensive technical support and after-sales service.

Frequently Asked Questions

Who are we?

Our factory is located in Wuxi, China with a branch company in Dongguan, established in 2016. We export to Southeast Asia, Mid East, Africa, South Asia, Northern Europe, and Eastern Europe.

Why select us?

We are high-end quality punching machine manufacturer committed to customer satisfaction.

Delivery time?

Usually 25 to 40 working days after receiving advance payment.

After-sale service?

Our technical and quality team provides continuous support.

Custom colors?

Yes, we can customize machine colors to match your production line.

Touch screen languages?

Yes, we can provide interface in Spanish, French, and other languages.
