Name: Uncoiler Leveling Metal Coil Straightening Steel Plate Flattening Machine Feeder 3 in 1
Brand: Dongguan Qiaosen Machinery Co., Ltd.
SKU: HCK4-600S
Price: 2.00 USD
Availability: InStock

Home > Products > Leveler Machine >

Uncoiler Leveling Metal Coil Straightening Steel Plate Flattening Machine Feeder 3 in 1

Uncoiler Leveling Machine

Metal Coil Straightening Machine

Steel Plate Flattening Machine 3in1

Place of Origin:

China

Brand Name:

QIAOSEN

Certification:

CE / ISO14001

Model Number:

HCK4-600S

Chat Now

Request A Quote

Product Details

Place Of Origin:

Guangdong, China

Type:

Feeder Machine

Use:

Sheet

Video Outgoing-inspection:

Provided

Machinery Test Report:

Provided

Core Components:

PLC, Bearing, Motor, Pump

Brand Name:

Qiaosen

Voltage:

380

Power(w):

2HP

Dimension(l*w*h):

5150*2258*3398mm

Warranty:

1 Year

Key Selling Points:

Easy To Operate

Weight (kg):

4000

Feeding Speed:

Item Name:

Pneumatic & Mechanical Feeding Straightening Feeder

Keyword:

Straightening Feeder Machine

Width Of Material:

600-1300mm For Aa4c Alloy Wheel Straightening Machine

Thickness Of Material:

0.5-4.5mm For Automatic Flattener

Max Correction Speed:

16/min For Automatic Level Machine

Main Motor:

AC22kw For Automatic Uncoiler Metal Sheet Opening Machine

Max Material Weight:

5000kg For Level Punching Machine

Coil Inside Diameter:

508mm For Leveler

Coil Outside Diameter:

1400mm For Uncoiler

Voltage:

Customized For Copper Straightening Machine

Highlight:

Uncoiler Leveling Machine

Metal Coil Straightening Machine

Steel Plate Flattening Machine 3in1

Payment & Shipping Terms

Minimum Order Quantity

Price

$56,000/cases 1-4 cases

Packaging Details

WOODEN BOX

Delivery Time

15-25

Payment Terms

T/T

Supply Ability

100SET per month

Industrial Sheet Leveler Machine with 9 Leveling Hoops Electronic Straightening Adjustment

Chat Now

Metal Coil 3 in 1 Decoiler Straightener Feeder Hydraulic Automatic Coil Uncoiling NC Servo Feeding

Chat Now

Uncoiler Leveling Metal Coil Straightening Steel Plate Flattening Machine Feeder 3 in 1

Chat Now

+8618103059517

tina_07@qiaosenmachinery.com

86-0769-26626853

Chat Now

Product Description

automatic steel plate metal sheet decoiler metal material straightening leveling and feeder machine

PRODUCT SPECIFICATIONS

Model	HCK4-600S	HCK4-800S	HCK4-1000S	HCK4-1300S
Coil width(mm)	70-600	70-800	70-1000	70-1300
Coil thickness(mm)	0.6-6.0
Max coil weight(kg)	5000	5000	7000	10000
Coil I.D(mm)	508
Coil O.D(mm)	1400
Max speed(mm)	16
Feeding accuracy(mm)	±0.15
Correction roll(mm)	Upper 5/lower 4
Feeding roll(set)	1
Back pressure roll(set)	provided
Feeding line height(mm)	1200±100
Power supply	AC220V 50HZ/AC380V 50HZ
Uncoiler expansion method(mm)	hydraulic
Air pressure(kg/cm^2)	5
Servo motor(kw)	AC22
Uncoiler motor(kw)	2.2	2.2	3.7	7.5

Feature:

1.Uses 9 leveling hoops,Effective enhances the material to rectify the even precision.

2.Electronic Straightening Adjustment: The NLF series features an automatic system for straightening adjustment,unlike previous models.Which adjusted straightening with manual wheels.The new electronic straightening system is easytouse and allows for faster setting up.

Company Profile

Dongguan Qiaosen Machinery Co.,Ltd which have our own factory located in Jiangsu province, established in 2016,Closed to shanghai city and transportation is very convenient, a birth place of creative minds and gifted talents. Our factory took the lead in passed authentication of the ISO9001:2008 quality management system . A factory specialized in the production of pneumatic press machine. Mainly products 25 tons to 1600 tons press machine with 8 series, have more than 100 types, link single column, four column, c frame, h frame and all kinds of press machine, punching machine, folding machine, cutting machine, is used in aviation, space flight, automobile, ship, light appliance, daily used hardware and so on. All along, the company products with exquisite design, reasonable price, excellent quality and efficient after-sales service and technical support, received the affirmation of customers at home and abroad, sell well in more than 20 domestic provinces, cities and districts, and exported to United States, Japan, Russia, European Union, southeast Asia, the Middle East and other countries.

FAQ

Q: Are you manufacturer?
A: Yes, we are manufacturer for more than ten years.
Q: What kind of payment term you can do?
A: We are flexible about payment terms, please contact us for details.
Q: What info you need before you make the proposal for a roll forming machine?
A: The profile drawings, material informations, your special requirements.
Q: What I should do if I just start to know roll forming machinery?
A: Contact us immediately, we provide free consultant pre-sales service.
